DND Machinery Pvt. Ltd is a leading Manufacturer, Supplier and Exporter of Agricultural Film Punching Machine in Madhya Pradesh, India.
Our manufacturing unit is in Ahmedabad, Gujarat, India.
A Mulch Film Punching Machine creates uniform holes or slots in mulch films, serving as specialized equipment for agricultural use.
These punched holes enable planting seeds, seedlings, or saplings while preserving mulch benefits like moisture retention, temperature regulation, and weed suppression.
The MFPM 1500D4W is a fully automated, high-efficiency machine engineered for seamless operation and consistent punching accuracy.
Process of Mulch Film Punching:
Loading: Mulch film rolls are loaded into the machine.
Feeding System: The film is fed automatically to the punching unit.
Punching Operation: High-precision punching tools create holes at pre-set distances.
Output: The punched film is rolled out, ready for application in the field.
Consistency: Ensures uniform spacing and accurate punching without damaging the film.
Specifications:
Model: 1500D4W.
Film Size (Min/Max): 1000 mm / 1500 mm.
Unwinder Roll Diameter (Max): 600 mm.
Unwinder Roll Weight: 300–350 kg.
Film Thickness (Min/Max): 15 / 50 Micron.
Machine Line Speed: 50 – 60 MPM.
Machine Output Speed: 200 – 240 MPM.
Punching Tool Size: 55 mm, 65 mm, 75 mm (Standard).
Number of Punches: 6 Nos.
Electronic Edge Guide Unit: Yes.
Auto Stop at Meter Completed: Yes.
Rewind Roll Length (Max): 1600 Mtr.
Rewind Roll Diameter (Max): 300 mm.
Material to Use: Mulch Film.
Total Load: 7 KW / 9.3 HP.
Dimensions (L × W × H): 5300 × 2700 × 1500 mm.
Applications:
The Mulch Film Punching Machine is widely used in:
• Vegetable Farming (tomato, chili, brinjal, cucumber, etc.)
• Fruit Farming (strawberries, watermelon, muskmelon, papaya, banana, etc.)
• Floriculture & Nursery Management
• Large-Scale Commercial Farming Projects
• Organic Farming with Biodegradable Mulch Films
FAQs:
Q1. What is the purpose of the Mulch Film Punching Machine?
It creates uniform holes in mulch films for planting seeds and seedlings while maintaining soil protection and crop benefits.
Q2. Can this machine handle biodegradable mulch films?
Yes, the MFPM 1500D4W is compatible with LDPE, HDPE, LLDPE, and biodegradable mulch films.
Q3. How many holes can it punch at once?
The 4-way punching system allows high-speed, multiple punching in one pass.
Q4. Is the machine easy to operate?
Yes, it features a user-friendly interface with adjustable settings for hole size and spacing.
Q5. What crops benefit from mulch film punching?
It is widely used for vegetables, fruits, flowers, and nurseries such as tomato, chili, strawberry, watermelon, and more.
DND Machinery Pvt. Ltd is a Manufacturer and Supplier of Agricultural Film Punching Machine in Madhya Pradesh, India Including Agar, Malwa, Alirajpur, Anuppur, Ashoknagar, Balaghat, Barwan, Betul, Bhind, Bhopal, Burhanpur, Chhatarpur Chhindwara, Chhindwara, Damoh, Datia, Dewas, Dhar, Dindori, East Nimar, Guna, Gwali-or, Harda, Hoshangabad, Indore, Jabalpur, Jhabua, Katni, Mandla, Mandsaur, Morena, Narsinghpur, Neemuch, Niwari, Panna, Raisen, Rajgarh, Ratlam, Rewa, Satna, Sehore, Seoni, Shahdol, Shajapur, Sheopur, Shivpuri, Sidhi, Singrauli, Ujjain, Umaria, Vidisha, West Nimar.
Feel free to contact us for more information and inquiries.
